Seas 27TBCD GB-DXT (H1499) | selected pair | matched pair

Features

High-quality 26 mm tweeter with DXT sound guide. A constant-directivity behavior (constant directivity) is achieved in a suitable baffle. Used in loudspeakers of the DXT-MON and DXT-Wave series.

Here as a selected pair. The maximum deviation between the tweeters from 1-10Khz is +-0,5dB, regular +-0,25dB.

• Power handling (nominal/music) = 55/150 W
• Frequency range = 2000-25000 Hz
• Resonance frequency fs = 900 Hz
• Impedance R = 6 ohms
• Characteristic sound pressure SPL = 92 dB (2,83V; 1m)
• DC resistance Re = 4,8 ohms
• Force Factor BL = 3,7 N/A
• Voice coil inductance L = 0,05 mH
• Effective membrane area Sd = 7,5 cm²
• Moved mass including air load mms = 0,33 g
• Voice coil diameter = 26 mm
• Linear deflection x_linen = +/- 0,25mm
• Installation diameter d = 85 mm
• Outer diameter d = 103,5 mm
• Installation depth (not milled) t = 59,3 mm
